Solar Hybrid PCU with Bluetooth

First Solar Hybrid PCU with Bluetooth based mobile application lunched by Su-vstika. This is the Solar PCU with Bluetooth application which can be represented with the mobile app very easily as it has so many settings and scenarios to understand and for the common man it’s very tough to understand Solar PCU without the mobile application.

bluetooth pcu app

Let us try to understand the Solar Hybrid PCU first. We call it solar hybrid PCU because it has the off Grid Solar along with the Grid power which is use to charge the battery. in off grid solar application the battery is being charged through the solar and there is no grid present so the solar energy is only use to power the house and appliances. Where as the Solar Hybrid PCU the grid is also available and the solar is also available and how this Solar Hybrid PCU works can be shown through the animation and the mobile application very easily.

So in the first scenario we are showing that the grid is not available and the solar energy is available and battery is being charged through the solar and load is also running on the solar. We have to understand that if the load is lesser than solar energy than only battery will be charged in this case. So the solar energy is flowing through the battery while charging and discharging the battery simultaneously as the solar power is always connected through the battery only in case of the Hybrid Solar PCU.https://suvastika.com/benefits-of-bluetooth-hybrid-solar-pcu/

This is another scenario where the battery got fully charged and solar power is also available than our solar hybrid PCU will cut the grid power and utilise the solar power so that the solar power doesnt get wasted. In this scenario there will be possibility of battery being charged and the load is running or battery is being discharged along with the solar power to run the load. It depends on the power being utilized by the load if house load is lesser than the solar power available than the solar power will charge the battery and supply the power to the home. But if the house has more load than the solar power available than the solar power along with the battery power will run the house load so in this case battery will be discharging.https://suvastika.com/what-is-hybrid-solar-pcu-solar-hybrid-off-grid-system/

In another scenario both the grid Power is also available and the solar power is also available than the Grid power will be running the house load and the solar power will charge the battery. There can be two scenarios in this if the solar power is enough to charge the battery than it will only chaarge the battery but if it is not enough power to charge the battery than the battery will be charged from both sources from the grid and from the solar power also.https://en.wikipedia.org/wiki/Hybrid_power

Solar PCU Scenario

Another scenario is that Grid is available and solar is not available in that case the battery will be charged and Grid power will be running the load. Mostly it will be the night mode or a cloudy day and battery be kept will be kept charged through the grid so that in case the grid fails than back up is given by the battery.
