How to Choose the Right Low Voltage Battery Cutoff (LVC)

How to Choose the Right Low Voltage Battery Cutoff (LVC) in Inverter/UPS is a very important parameter to understand. A low-voltage battery cutoff (LVC) is a device or feature inside the Inverter/UPS that disconnects a battery from a load when the voltage drops below a certain level. This helps to prevent the battery from being deeply discharged, which can damage the battery.https://en.wikipedia.org/wiki/Cutoff_voltage

The LVC is typically 10% below the battery’s nominal voltage. For example, a 12V  Tubular lead Acid battery might have an LVC of 10.8V. This means the LVC will disconnect the battery from the Load when the voltage drops to 10.8V. For the lithium battery, this cutoff is at higher voltages as the Lithium battery LifePo4 has a voltage of 12.8 Volts, so the cutoff voltage for a Low battery is 11.2 Volts. This voltage keeps the Lithium battery safe because the BMS inside the battery keeps working. The battery voltage is reduced until BMS switches off, generally switched off at around 9.5 Volts. If the Mains power takes a long time to come back, the lithium battery might go to deep discharge as the BMS keeps taking the current and taking the battery below a certain level from where the battery needs an external charger to charge.https://www.researchgate.net/figure/Schematic-diagram-for-low-battery-cut-off-The-inverter-feedback-section-maintains-a_fig7_264158214

What is the difference between a low-voltage battery cutoff for a lead acid battery versus a lithium battery?

The Low Battery voltage cutoff in the lead Acid is kept at 10.5 Volts to keep it safe. The low cutoff voltage for the 3.2 Volt lithium battery cell of LifePO4, having a 12.8-volt battery, is kept at 11.2 volts as the built BMS keep taking the current during the ideal condition of the battery, so to keep it safe, its recommended to keep it 11.2 volts.



Lithium Battery

Lithium battery pic

water topping in the Tubular battery

water topping in the tubular battery.

How does the low-voltage battery cutoff work in the Su-vastika Inverter/UPS?

In Su-vastika Pure Sinewave UPS with ATC model, we can use Lead Acid batteries like Tubular, SMF and gel batteries and the option of using Lithium battery LifePo4 chemistry. Also, there is an option to change the LVC to 4 preset voltages like 10.5, a default voltage setting, along with the 10.8, 11.0 and 11.2 Volts.

This is shown in the mobile application as battery Reserve Mode settings which start from 0%,3%, 5%,8% and 10%. So 0% is 10.5V, 3% is 10.8, denotes 5%, and 11.2 is 8%.

The higher the Low Voltage settings, the better the battery life because the DOD can be reduced in this case, and the lower the DOD in the battery, the higher the life of any battery.

This feature also helps the user as it works like reserve in a scooter. If the user sets the reserve mode to 8% and when the Inverter/UPS battery stops after giving it back up, the user can change the setting to 0% and get back up from the battery as it was reserved in the battery.https://suvastika.com/lvc-low-voltage-cutoff-and-its-significance-for-batteries/

There is a mobile app from where you can do the settings in the setting section, and the moment the user selects any battery, the picture of that battery will be visible all the time so that the user can correct it in case he did the wrong setting. The moment the customer chooses the Lithium battery, the Lithium battery’s low voltage cutoff is automatically selected, which is kept at 11.2 volts.

If you are considering using battery reserve mode, you should weigh the benefits against the drawbacks. The main drawback of battery reserve mode is that it will reduce the power you can use from your battery. If you have a large battery, this may not be a problem. However, you may consider setting a lower reserve level if you have a small battery.







mobile app showing low battery cut off

mobile application of Inverter/UPS

In Su-vastika Inverter/ UPS, the warning for low battery starts at 10.8 volts, and this gives a warning with audio and LCD/LED messages. If the user can reduce the Load, then this warning goes off as the battery voltage is recovered if the Load is reduced. But when the battery is almost discharged, then at a smaller load, this warning comes, and even if the user reduces the Load, it will come to 10.5 Volts and then switch off the Inverter/UPS till the Mains Power come back. Most of our inverters/UPS/Solar inverters/PCU give you a Low battery alert four times. If the user doesn’t reduce the Load during that time, it goes to Low battery cutoff mode, and the user has to reset the front switch of the inverter to restart the inverter functioning by reducing the Load. In Su-vastika UPS, there is a provision to add WiFI or Bluetooth to the UPS, and then at the mobile app user can see the low Voltage warning and can reduce the Load as the mobile app gives the sign of Low battery and the Load is switched on and off for three times and during that period if the user reduces the Load than it stop this warning for some more time and continue functioning. But once the battery is very low than at a smaller load, also it gives the warning and switches off the Load to save the battery from going to deep discharge.

Here are some of the benefits of using a low-voltage battery cutoff:

  • It prevents the battery from being deeply discharged, which can damage the battery.
  • The LVC is different for Lead Acid batteries and Lithium batteries.
  • How does the low-voltage battery cutoff work in the Su-vastika Inverter/UPS/Solar Inverters/PCU
  • The higher the settings for reserve mode, the life of the battery will increase.
  • The Reserve mode helps the user get more backups in an emergency.

How to Choose the Right Low-Voltage Battery Cutoff (LVC) for Inverter/UPS The life of the battery is enhanced If you use a battery in a critical application, a low-voltage battery cutoff is essential. This will help to protect the battery from damage and extend its life.

Written by Kunwer Sachdev https://g.co/kgs/JFLwWN
